Low Impedance Custom Industrial Kickless Cables For Suspension Spot Welder

Basic Information
Place of Origin: China
Brand Name: XWH
Model Number: XW
Minimum Order Quantity: 5
Price: USD300-USD350
Packaging Details: Wooden Case
Delivery Time: 15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 sets/month
Detail Information
Certification: CE, ISO Product Name: Kickless Cable
Application: Industrial Welding Usage: Welding Accessroies
Conductor Material: Pure Red Copper Standard Diameter: 300mm²/400mm²
Standard Length: 2m-3.5m Feature: Low Impedance
After Warranty Service: Video Technical Support, Online Support And Spare Parts After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training
High Light:

Industrial Kickless Cables

,

Custom Kickless Cables

,

Industrial Welding Secondary Cable


Product Description

Low Impedance Custom Industrial Kickless Cable Cables For Suspension Spot Welder





Product Description

The electrode of the kickless cable is made of integral copper bar by turning and milling; The wire is made of enameled wire woven by copper stranded wire or CNC winding machine, with high flexibility and small bending radius; The outer protective sleeve is made of high-quality rubber tube, which is resistant to high pressure. The sleeve and electrode are processed by cold extrusion and fixed on professional equipment with stainless steel clamps, which have good sealing and are not prone to leakage.



Parameter



Item Specifiction 300mm² 400mm² Note
Impedance 2.0M 480±15μΩ 358±15μΩ
2.4M 593±15μΩ 445±15μΩ
Dc impedance value 2.0M 475μΩ 355μΩ
2.4M 587μΩ 440μΩ
Resistance 2.0M 78μΩ 74μΩ Calculated Value
2.4M 82μΩ 88μΩ
Power   =0.99 =0.99
Cooling water capacity   7.0L/MIN 7.0L/MIN Pressure Loss of 0.7KG/cm
Temperature rise characteristic 2.0M 45℃/5900A 45℃/6800A
2.4M 45℃/5400A 45℃/6200A
Weight 2.0M 10.4KG 13.2KG Average Value
2.4M 12.2KG 15.3KG





Features



1. High-purity red copper hinge cables, having higher conductivity and lowering impedance between the transformer output and the welding gun



2. Excellent rubber sleeves and plum blossom rubber cores, having good pressure resistance, heat resistance, wear resistance, and bending performance



3. High resistance to repeating kicks and bending caused by electro-magnetic force induced by welding current and welding operation, and accordingly long life and good economy.



4. Minimal water pressure drop for excellent cooling effect



5. Convenient cable replacement and minimal downtime





Standard Drawing

Cross Section 300mm²

Low Impedance Custom Industrial Kickless Cables For Suspension Spot Welder 0







Cross Section 400mm²

Low Impedance Custom Industrial Kickless Cables For Suspension Spot Welder 1

Besides standard models, we can customized according to your requirements. More details, please contact!



Scene images

Raw Materials: Pure Red Copper

Low Impedance Custom Industrial Kickless Cables For Suspension Spot Welder 2

Careful Protection :Additional Rubber Sleeve

Low Impedance Custom Industrial Kickless Cables For Suspension Spot Welder 3



Finished Product

Low Impedance Custom Industrial Kickless Cables For Suspension Spot Welder 4




Application



Low Impedance Custom Industrial Kickless Cables For Suspension Spot Welder 5





Frequently Asked Questions

1. When can you arrange shippment?
The shippment is 15 days after getting deopsit, but customized machines should be more than 25 days.

2.Do you inspect the finished products?
Yes, each step of production products will be came out inspection by QC department before shipping.

3.Are you factory?
Yes, we are factory, all machine is made by ourself and we can provide customize service according to your requirement.

4.How to buy your Spot Welder?
Please send us inquiry to our email, and we will give you a PI to send us payment.

5. How to contact you?
You can send a mail for us and call us.

6.How will you deliver my goods to me?
We always ship by air and sea in the mean time.

7.How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.

8.What kind of payment do you accept?
T/T, Western Union, PayPal, .L/C, D/A, etc.
