Fiber Manual Handheld Laser Beam Welder For Stainless Steel

Basic Information
Place of Origin: China
Brand Name: XWH
Certification: CE, ISO
Model Number: XW-1000W, XW-1500W, XW-2000W
Minimum Order Quantity: 1
Price: USD3500-USD7500
Packaging Details: Wooden Case
Delivery Time: 15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 sets/month
Detail Information
Product Name: Cnc Laser Welding Machine Welding Material: Aluminum, Stainless Steel, Metal Steel
MOQ: 1 Set Application: Fiber Laser Welding
Cooling System: Build-In Water Cooling Function: Laser Welding, Cutting And Rusts Removal
After Warranty Service: Video Technical Support, Online Support And Spare Parts After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training
High Light:

Handheld Laser Beam Welder


Fiber Manual Laser Beam Welder


2.0m/min SS Laser Welder Machine

Product Description


China Best Hand Held Fiber Manual Handheld Laser Beam Welder For Stainless Steel

Product Description
Portable laser welding machine is a new type of welding, is also one of the important aspects of the application of laser material processing technology. Laser welding is mainly for the welding of thin-walled materials and precision parts. The welding process belongs to the heat conduction type, that is, laser radiation heats workpiece surface and surface heat diffuses to the interior through heat conduction. By controlling the parameters of laser pulse width, energy, peak power and repetition rate, the workpiece is melted to form a specific molten pool. The laser welder is not only for laser welding, but also for rusts removal and cutting.

 Technical Parameters


ItemsModels XW-1000W XW-1500W XW-2000W
Laser Power 1000W 1500W 2000W
Laser Length Customized Customized Customized
Total Power ≤6KW ≤7KW ≤9KW
Conduction Types Optical Fiber Optical Fiber Optical Fiber
Output Mode Standard QBH Standard QBH Standard QBH
Laser Line 1080±nm 1080±nm 1080±nm
Power Supply 220V±10% AC 220V±10% AC 220V±10% AC
Working Humidity <70% No Condensation <70% No Condensation <70% No Condensation
Working Temperature -10℃-45℃ -10℃-45℃ -10℃-45℃
Cooling System Industrial Chiller Industrial Chiller Industrial Chiller
Welding speed 0.7-2.0m/min 0.7-2.0m/min 0.7-2.0m/min
Operation System Hand-held Welding Hand-held Welding Hand-held Welding
Standard Output ±2% ±2% ±2%
Weight ≤185KG ≤185KG ≤185KG
Power Source 220V/50Hz/40A 220V/50Hz/60A 380V/50Hz/60A
Dimension 1000*600*1200mm 1000*600*1200mm 1000*600*1200mm



1. Weld width is adjustable and wire feeding welding is automatic.
2. It is 5-10 times faster than traditional welding and argon arc welding processes.
3. Beautiful weld, no deformation, no blackening, no need to polish.

4. Outdoor welding, casters moving.

5. Long distance welding and any angle/shape welding.

6.There is no need for professional welders, ordinary people can weld beautiful workpiece.

7.Welding materials: stainless steel, carbon steel, galvanized sheet and other metals.



Schematic Diagram of Product Structure


Fiber Manual Handheld Laser Beam Welder For Stainless Steel 0



①Hand held welding joint                                                                             ②Consumable accessories kit

③Control Panel④Optical Master⑤Wire Feeder                                          ⑥Consumable accessories kit

⑦Emergency Stop Switch, Key Switch, Power Button                                 ⑧Conducting Wire


Cooling Water Requirements


The resistivity of purified water is generally required to be greater than 0.5M Ω Cm, after using for a period of time, the resistivity of the water will decrease or impurities, dirt, water turbidity and other phenomena in the water will make the xenon lamp point show wrong, otherwise it will pollute the surface of the laser cavity and glass tube, reducing the optical efficiency. At this time, it should be immediately replaced with pure water (deionized water is used continuously in the system, and it should be replaced once a week).




Fiber Manual Handheld Laser Beam Welder For Stainless Steel 1
Frequently Asked Questions
1. When can you arrange shippment?
The shippment is 15 days after getting deopsit, but customized machines should be more than 25 days.

2.Do you inspect the finished products?
Yes, each step of production products will be came out inspection by QC department before shipping.

3.Are you factory?
Yes, we are factory, all machine is made by ourself and we can provide customize service according to your requirement.

4.How to buy your Spot Welder?
Please send us inquiry to our email, and we will give you a PI to send us payment.
5. How to contact you?
You can send a mail for us and call us.

6.How will you deliver my goods to me?
We always ship by air and sea in the mean time.

7.How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.

8.What kind of payment do you accept?
T/T, Western Union, PayPal, .L/C, D/A, etc.
Fiber Manual Handheld Laser Beam Welder For Stainless Steel 2
Fiber Manual Handheld Laser Beam Welder For Stainless Steel 3
Fiber Manual Handheld Laser Beam Welder For Stainless Steel 4
Fiber Manual Handheld Laser Beam Welder For Stainless Steel 5
Fiber Manual Handheld Laser Beam Welder For Stainless Steel 6
