Metal Automatic Rebar Mesh Heavy Duty Machine For Welding Resistance Spot Welder

Basic Information
Place of Origin: China
Brand Name: XWH
Certification: CE
Model Number: D(N)B--160, D(N)B--200, D(N)B--250
Minimum Order Quantity: 1
Price: USD35000-USD40000
Packaging Details: Wooden Case
Delivery Time: 15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 sets/month
Detail Information
Product Name: Full Automatic Fire-proof Door Stationary Spot Welders Welding Material: Steel Copper Aluminum
Feature: Stable Welding Current Machine Type: Resistance Welding Machine
Application: Industrial MOQ: 1 Set
After Warranty Service: Video Technical Support, Online Support And Spare Parts After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training
High Light:

Rebar Mesh Heavy Duty Machine

,

CE Resistance Spot Welder


Product Description

 Metal Automatic Rebar Mesh Heavy Duty Machine For Welding Resistance Spot Welder 0





Metal Automatic Rebar Mesh Heavy Duty Machine For Welding Resistance Spot Welder



Product Introduction

The stationary spot welding machine is customized for fire-proof door. The welding machine is composed of rack, workpiece moving platform, welding machine moving mechanism, upper and lower electrodes, welding transformer, welding machine controller, PLC controller, air circuit system, cooling water circuit system and other components.



Technical Parameters



Models/Item D(N)B--160 D(N)B--200 D(N)B--250
Rated power (KVA) 160 200 250
Power input(V) 3φAC 380V 3φAC 380V 3φAC 380V
Max. short circuit current(KA) 40 40 45
Max. force (N) 6000 10000 15000
Electrode length(MM) 450 450 500
Working stroke(MM) 80 80 80
Cooling consumption(L/min) 20 20 20
Max.welding capacity(MM) 4.0+4.0 5.0+5.0 6.0+6.0





Advantages



1. Stable machine structure upside and downside of electrodes apply the pressure mode with assistant stroke. The welding efficiency is much higher.



2. The transformer of welding machine adopts the special resistance welding machine, the silicon steel slice is featured of high magnetic: the inner water- cooled by force; stronger power and high duty ratio.



3. Controlled by micro-computer and can saved at most 16 sets of welding settings, which is quite convenient for different kinds of welding sheets.



4. Can widely used in nut, studs, traffic tools, household items, cars. And it can be welded low-carbon steel, stainless steel, coated steel, non-ferrous metal wire, sheet, pipe, etc.





Structure



Components of Welding Machine:

The fire door spot welding machine consists of a frame, a workpiece moving platform, a welding machine moving mechanism, upper and lower electrodes, a welding transformer, and a welding machine controller, PLC controller, air circuit system, cooling water circuit system and other components.



Metal Automatic Rebar Mesh Heavy Duty Machine For Welding Resistance Spot Welder 1



Pneumatic Transmission Mechanism:

When the fire door spot welding machine is used for welding, the lowering of the upper electrode and the pressing of the weldment are realized by the pneumatic transmission mechanism,the mechanism is composed of cylinder, piston, guide rod, sealing ring, sealing ring, etc.



Metal Automatic Rebar Mesh Heavy Duty Machine For Welding Resistance Spot Welder 2

Air Circuit System:

The air circuit system is composed of ball valve, air filter, pressure reducing valve, oil atomizer, electromagnetic air valve, cylinder, etc.

Metal Automatic Rebar Mesh Heavy Duty Machine For Welding Resistance Spot Welder 3

Working Principle



Install the workpiece: the rear positioning block and the right positioning block are used as the reference positioning block. To adjust, the motor zero point needs to be corrected. Other positioning blocks can be adjusted close to the workpiece. The side floating positioning block clamps the framework of the workpiece and the panel together to avoid the displacement of the welding spot. (The manual clamping screw fixes the workpiece on the side floating positioning block).



Welding: after the start (automatic) switch is pressed, the program automatically controls the action of the equipment to complete the product until the stop button is pressed.



Metal Automatic Rebar Mesh Heavy Duty Machine For Welding Resistance Spot Welder 4





Control System Functions



Specific functions are as follows:

1. BCD code: welding procedure can be selected by BCD code.

2. Communication: it can communicate with the robot through the field bus to realize automatic welding. ProfiNet, DeviceNet, EtherNet/IP, CC_ Link and other communication methods can be selected.

3. Manual/automatic conversion: in manual mode, it is controlled by mainboard I/O, and in automatic mode, it is controlled by communication.

4. CD touch screen display: full Chinese menu display, rich display content, convenient parameter setting.
