Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate

Product Introduction:

Designed specifically for automotive braking systems, this automated spot welding system for carbon steel brake backing plates represents advanced welding technology integration. The equipment employs either Medium Frequency Direct Current (MFDC) inverter technology or capacitor discharge welding methodology, combined with servo-driven actuation and programmable logic controller (PLC) automation. It delivers precision spot and projection welding for carbon steel substrates (Q235/SPHC grades, 1-6mm thickness range).

Features:

1. The system shall incorporate an electro-proportional pressure regulation valve with ±0.5% full-scale accuracy for dynamic welding force control.

2. The system features comprehensive insulation protection for enhanced safety. The secondary circuit utilizes a pressurized cylinder base with insulated upper arms, enabling direct installation and welding operations on the lower base without short-circuit risks—simple yet highly functional.

3. Welding power supply, energy-saving and efficient. The main welding circuit adopts a fully water-cooled resistance welding transformer and rectifier, with strong output power.

4. Operators can control the welding process via an ergonomic foot switch, ensuring high-speed production with reduced physical strain for improved workflow efficiency.

5. The system features integrated pneumatic and hydraulic pressure monitoring with fail-safe alarms, preventing operation during insufficient coolant flow or gas supply conditions to ensure equipment protection.

Technical Parameters:

Items Models	DN(B)-100	DN(B)-160	DN(B)-200	DN(B)-250
Rated power (KVA)	100	160	200	250
Power input(V)	3φAC 380V	3φAC 380V	3φAC 380V	3φAC 380V
Max. short circuit current (KA)	30	35	40	45
Duty cycle(%)	50	50	50	50
Max. force(N)	6000	6000	10000	15000
Electrode length( MM)	450	450	450	500
Working stroke( MM)	80	80	80	80
Cooling consumption(L/min)	20	20	20	20
Max. welding capacity(MM)	3.0+3.0	4.0+4.0	5.0+5.0	6.0+6.0

General Structures:

Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate 0

Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate 1

Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate 2

Detailed Images:

Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate 3

Dual Cabinet Configuration: In addition to the conventional welding controller, the welding system is also equipped with an electrical control cabinet, which enables safer, more efficient, and intelligent operation, especially suitable for industrial scale large-scale or high-precision welding tasks.

Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate 4

Fully Automatic Welding: High compatibility, with 3 types of workpieces corresponding to 3 types of fixtures. Simply replace the positioning component to achieve model change. Fully automatic welding, automatically moving the point position to complete the welding.

Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate 5

Gas Storage Tanks: The projection and spot welding machine is equipped with a dedicated gas storage tank, which is beneficial for reducing welding pressure fluctuations and ensuring stable welding force.

Spot Welder Automatic Projection Welding Machine Carbon Steel Car Brake Base Plate 6

Waterway Components: All waterway components undergo surface treatment to prevent rusting, and waterway drainage is independently discharged to the water tank. Based on the outflow situation, blockages in the waterway can be observed and eliminated.
