Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine

Basic Information
Place of Origin: China
Brand Name: XWH
Certification: CE
Model Number: DN-40, DN-63, D(T)N-80, D(T)N-100, D(T)N-125, D(T)N-125, D(T)N-200
Minimum Order Quantity: 1
Price: USD35000-USD40000
Packaging Details: Wooden Case
Delivery Time: 15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 sets/month
Detail Information
Product Name: Car Fuel Tank Welding Machine Application: Welding Fuel Tank
Function: Projection Welding Machine Type: Resiatance Welding Machine
Keyword: Professional Welding Machine Welding Material: Alloy Metal Aluminum Stainless Steel
Feature: Stationary Welding Machine After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training
After Warranty Service: Video Technical Support, Online Support And Spare Parts Certification: CE
High Light:

Hail Damage Auto Spot Welder

,

Manual Copper Welding Auto Spot Welder


Product Description



Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine



Product Introduction


The multi head stationary spot welder is customized for welding the car fuel tank. This stationary Spot Welding Machine is working on the 380V/50Hz three-phase AC power supply.By the three-phase rectifier, inverter technology and the feedback control system, to control the welding heat, pre-press time, the maintenance time and cease time, achieving the welding requirements. The machine is widely used in automobile, home appliances, electronic instrumentation, aerospace and other projection welding process industry.




Technical Parameters



Item/Model   DN-40 DN-63 D(T)N-80 D(T)N-100 D(T)N-125 D(T)N-160 D(T)N-200
Rated power At 50% KVA 40 63 80 100 125 160 200
Rated primary power V 380 380 380 380 380 380 380
Secondary Voltage V 5.2 6.7 7.9 8.3 8.6 9.1 10.6
Rated frequency HZ 50/60 50/60 50/60 50/60 50/60 50/60 50/60
Max.Short Circuit Current KA 14 15 16 18 20 28 34
Max. weld power KVA 62 86 170 280 300 330 410
Throat MM 500 500 630 630 630 630 630
Max.Froce at electrodes N 6000 6000 10000 10000 10000 12000 12000
Working stroke MM 20 20 30 40 40 50 50
Cooling Water Consumpion 2.5bar L/min 6 6 8 8 8 10 10
Electrodes tlp MM Φ13*45 Φ13*45 Φ16*45 Φ16*45 Φ16*45 Φ20*45 Φ20*45
Arms MM Φ50*150 Φ50*150 Φ80*220 Φ80*220 Φ80*220 Φ80*220 Φ80*220
Projection Clamping Plate MM 125*125 125*125 200*200 200*200 200*200 200*200 200*200

Max.Welding Capaciry A3 steel

MM 2.5+2.5 3+3 4+4 4.5+4.5 5+5 5+5 6+6





Advantages



1. The welding current is DC. When there are inductive/magnetic materials in the secondary winding, the welding will not be affected;



2. The three-phase power supply is more adaptable to the fluctuation and voltage drop of the power grid;



3. The process is more reliable, and DC welding will be better for most of the metals with resistance welding;



4. Reduce operation cost, including saving welding energy at each point and shortening welding cycle;





Main Structure and Fixture of the Equipment



The multi head spot welder is mainly composed of the equipment host, upper and lower electrode components, fixture components, welding controller, PLC controller, touch screen components, water and gas circuit components, etc.





Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 0

Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 1

Welding May Cause Fire and Explosion



When welding closed containers, such as tanks, boxes, pipes, and other workpieces, they may explode. The sparks generated by the arc during welding will splatter everywhere. Splashing sparks, hot workpieces, and heating equipment can cause fires and combustion. Unexpected contact between electrodes and metal objects, poor connection of welding cables, and poor contact of the current path on the welding substrate side can all cause sparks, overheating, explosions, and fires. Before welding, attention should be paid to inspecting and ensuring the safety of the working area.





Images



Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 2




Application





Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 3




Frequently Asked Questions

1. When can you arrange shippment?
The shippment is 15 days after getting deopsit, but customized machines should be more than 25 days.

2.Do you inspect the finished products?
Yes, each step of production products will be came out inspection by QC department before shipping.

3.Are you factory?
Yes, we are factory, all machine is made by ourself and we can provide customize service according to your requirement.

4.How to buy your Spot Welder?
Please send us inquiry to our email, and we will give you a PI to send us payment.

5. How to contact you?
You can send a mail for us and call us.

6.How will you deliver my goods to me?
We always ship by air and sea in the mean time.

7.How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.

8.What kind of payment do you accept?
T/T, Western Union, PayPal, .L/C, D/A, etc.


Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 4
Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 5
Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 6
Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 7

Industrial Fuel Tank Resistance Welders Spot Welder Multi Head Spot Welding Machine 8
