| Place of Origin: | China |
|---|---|
| Brand Name: | XWH |
| Certification: | CE |
| Model Number: | DN(B)-160, DN(B)-200, DN(B)-250 |
| Minimum Order Quantity: | 1 |
| Price: | USD30000-USD40000 |
| Packaging Details: | Wooden Case |
| Delivery Time: | 15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50 sets/month |
| Product Name: | Fuel Tank Welding Machine | Application: | Welding Machine For Oil Tank |
|---|---|---|---|
| Function: | Resistance Spot Welding | Machine Type: | Pneumatic Spot Welding |
| Keyword: | Welding Multi Spot Machine | Welding Material: | Stainless Steel |
| Feature: | High Production Efficiency | Warranty: | 1 Year Guarantee |
| After Warranty Service: | Video Technical Support, Online Support And Spare Parts | After-sales Service Provided: | Free Spare Parts, Field Installation, Commissioning And Training |
| High Light: | Stud Welder Dent Repair Machine,Suction Cup Dent Repair Machine |
||
Resistance Aluminum Fuel Oil Tank Welding Multi Poiant Welding Spot Welder Machine
Product Introduction:
Platform type spot welding machine is mainly designed for large metal workpieces in industries such as hardware, sheet metal, elevators, kitchenware, and automobiles.
Advantages:
1. The electrode pressurization is stable and fast: the aluminum alloy cylinder, low damping sealing ring, and light friction ring combination cylinder work stably.
2. Energy saving and efficient welding power supply: The welding controller adopts a commercial intermediate frequency controller, which is reliable in quality, stable in operation, and easy to operate.
3. All waterway components are made of stainless steel and equipped with a visual water flow display, which is conducive to monitoring the cooling situation of the electrode head and preventing the electrode head from overheating and reducing its lifespan; The main water inlet is equipped with a water filter to prevent blockages in the waterway.
4. The equipment has air pressure and water pressure switches and alarms. It can effectively prevent water or gas shortage during welding, thereby protecting the safety of equipment use.
Technical Parameters:
| Models/Item | DN(B)-100 | D(N)B--160 | D(N)B--200 | D(N)B--250 |
| Rated power (KVA) | 100 | 160 | 200 | 250 |
| Power input(V) | 3φAC 380V | 3φAC 380V | 3φAC 380V | 3φAC 380V |
| Max. short circuit current(KA) | 30 | 40 | 40 | 45 |
| Max. force (N) | 6000 | 6000 | 10000 | 15000 |
| Electrode length(MM) | 450 | 450 | 450 | 500 |
| Working stroke(MM) | 80 | 80 | 80 | 80 |
| Cooling consumption(L/min) | 20 | 20 | 20 | 20 |
| Max.welding capacity(MM) | 3.0+3.0 | 4.0+4.0 | 5.0+5.0 | 6.0+6.0 |
General Structures:
Workpiece:
Production Line:
Application:
FAQ:
