Portable Arc Aluminum Cd Welding Machine Steel Studs Weld Pro for Harbor Freight

Basic Information
Place of Origin: China
Brand Name: XWH
Certification: CE, ISO
Model Number: RSR-1600, RSR-2500, RSR-3500
Minimum Order Quantity: 1
Price: USD600-USD800
Packaging Details: Wooden Case
Delivery Time: 15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 sets/month
Detail Information
Product Name: Capacitive Energy Storage Stud Welding Machine Application: Stud Welding
MOQ: 1 Set Package: Wooden Case
Production Time: 15-20 Days Type: Energy Storage
After Warranty Service: Video Technical Support, Online Support And Spare Parts After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training
High Light:

Arc Aluminum Cd Welding Machine

,

Harbor Freight Cd Welding Machine

,

AC220 Steel Stud Welding Machine


Product Description



Portable Arc Aluminum Cd Welding Steel Studs Weld Pro Harbor Freight Stud Welder





Product Description



The energy storage stud welder can weld studs, internal thread studs, pins and other similar components to metal workpieces. During welding, discharge the energy storage capacitor by discharging the stud tip for 0.001-0.003 seconds, and the penetration is about 0.1MM. This method is applicable to the thin plate with a thickness of more than 0.4MM. The plate surface is free of welding seams, the back is free of indentation, discoloration, deformation and other defects. It is most suitable for the occasion where the surface requires decorative effect. The ratio of plate thickness to stud diameter is 1:10.





Technical Parameters



Item/Model
RSR-1600
RSR-2500
RSR-3000
Input Voltage (V)
AC220
AC220
AC220
Frequency (Hz)
50/60
50/60
50/60
Rated storage energy (J) 1600 2500 3000
Diameter of welding stud (mm)
M3~M6
M3~M8
M3~M10
Thickness of welding plate (mm)
0.2~1.0
0.2~2.0
0.2~3.0
Capacitance (uf) 720000 1080000 1440000
Productivity (pcs/minute) 20 20 20
Charging voltage (V)
30~200
30~200
30~200
Overall dimension (mm)
416*245*300
416*245*300
416*245*300
Weight (kg) 12 13 14
Protection Degree IP21S IP21S IP21S





Features



1. Continuously display the energy storage voltage, which is not affected by the fluctuation of input voltage, and can automatically adapt to the changes of power grid, with over temperature self-protection function
2. The panel is LCD, microprocessor controlled, and has expert welding specifications
3. Small size, light weight and convenient operation
4. The welding is firm, with less splash and beautiful welding
5. Suitable for stud welding of carbon steel, stainless steel, copper and aluminum.





Panel diagram



Portable Arc Aluminum Cd Welding Machine Steel Studs Weld Pro for Harbor Freight 0



Portable Arc Aluminum Cd Welding Machine Steel Studs Weld Pro for Harbor Freight 1





Safety Warning



Noise - excessive noise is harmful to people's hearing!

·Protect your ears, use ear shields or wear other hearing protection.

·Warn bystanders that noise may cause potential damage to their hearing.


Failure - seek professional help when encountering difficulties!

·If you encounter difficulties in installation and operation, please follow the relevant contents of this manual for troubleshooting.

·If you still cannot fully understand after reading, or cannot solve the problem according to the instructions of this manual, you should contact us immediately.





Samples



Portable Arc Aluminum Cd Welding Machine Steel Studs Weld Pro for Harbor Freight 2



Portable Arc Aluminum Cd Welding Machine Steel Studs Weld Pro for Harbor Freight 3



Portable Arc Aluminum Cd Welding Machine Steel Studs Weld Pro for Harbor Freight 4





Frequently Asked Questions


1. When can you arrange shippment?
The shippment is 15 days after getting deopsit, but customized machines should be more than 25 days.

2.Do you inspect the finished products?
Yes, each step of production products will be came out inspection by QC department before shipping.

3.Are you factory?
Yes, we are factory, all machine is made by ourself and we can provide customize service according to your requirement.

4.How to buy your Spot Welder?
Please send us inquiry to our email, and we will give you a PI to send us payment.

5. How to contact you?
You can send a mail for us and call us.

6.How will you deliver my goods to me?
We always ship by air and sea in the mean time.

7.How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.

8.What kind of payment do you accept?
T/T, Western Union, PayPal, .L/C, D/A, etc.
