Industrial Stainless Steel Custom Portable Spot Welding Machine Welders

Basic Information
Place of Origin: China
Brand Name: XWH
Certification: CE
Model Number: DN2
Minimum Order Quantity: 1 Set
Price: $6000 - $6500.00
Packaging Details: wooden Case
Delivery Time: 15 Working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Set/Sets per Week
Detail Information
Product Name: Portable Hand Held Welding Machine Function: Metal Spot Welding Machine
Machine Type: Resistance Welding Machine Application: Car Body Industry
Type: Manual Spot Welding Max. Welding Thickness: 5+5 Mm
Rated Capacity: 60KVA, 80KVA, 100KVA After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training
After Warranty Service: Video Technical Support, Online Support And Spare Parts Certification: Certification
High Light:

Custom Portable Inverter Welding Machine

,

SS Portable Inverter Welding Machine

,

Portable Inverter Spot Welders


Product Description




Industrial Stainless Steel Custom Portable Inverter Welding Machine Welders



Product Description



The portable spot welding machine uses the resistance heat generated by the current flowing through the weldment as a heat source for welding under pressure. Mainly used for spot welding of low-carbon steel parts of thin plate structures.



Item/models Unit DN2-31X DN2-31C DN2-40X DN2-40C DN2-63X DN2-63C
power at 50% KVA 31 31 40 40 63 63
Maximum short circuit current KVA 14 14 18 18 20 20
Secondary unload voltage V 5.58 5.58 6.8 6.8 7.9 7.9
Voltage at 50Hz/60Hz V 380 380 380 380 380 380
Distance between the arms MM

168-288

100 168-328 100 168-428 100
Max.strength at electrodes N 3000 3000 3500 3000 3500 3000
Working stroke MM 15-45 15-25 15-45 15-25 15-45 15-25
Max.stroke of cylinder MM 70 50 100 50 100 50
Max. arm length MM 750 350 1000 450 1100 500
Compressed Air supply MPA 0.5 0.5 0.5 0.5 0.5 0.5
Max thickness of mild steel sheet with min.length s arm MM 3+3 3+3 4+4 4+4 5+5 5+5
With 500mm arms MM 2+2 2+2 3+3 3+3 3+3 3+3
With maximum length arms MM 1.2+1.2 1.2+1.2 2+2 1.8+1.8 2.0+2.0 2.0+2.0
Cross wire maximum MM 14+14 14+14 16+16 16+16 20+20 20+20
Cooling water pressure drop MPA 0.2-0.3 0.2-0.3 0.2-0.3 0.2-0.3 0.2-0.3 0.2-0.3
Cooling water flow L/MIN 4 4 4 4 4 4



♦ Distance,angle and length of welding arm can be made according to customers' requests.





Features:



1. Small, easy to operate and save power.



2. The structure is compact and is easy to maintenance.



3. The portable spot welders can rotate 360°as the turntable is configured with bearings.



4. Customized welding tongs, the longest welding arm is 1300mm and the shortest is 220mm.



5. The body structure is strong and resistant to damage.





Application:



The portable spot welding machine is widely used in automobile manufacturing, maintenance, household appliances, doors and Windows, agriculture, construction steel and other metal manufacturing industries.





General Structures





Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 0





Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 1





Mutiple Electrode Arms

Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 2



Power Frequency Controller



1) The controller has an adjustable output current function.



2) The controller has a constant current automatic compensation control function to ensure a constant output of welding current, with a platform order of up to ten.



3) Can store multiple sets of different welding specifications, at least not less than 2 sets. And it is convenient to select groups on the welding machine.



4) Equipped with single spot welding and continuous welding functions, as well as welding specification functions such as multi pulse selection, the welding current pulse count can reach nine.

Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 3

Use & Installation



Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 4



Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 5



Images



Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 6

Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 7





Industrial Stainless Steel Custom Portable Spot Welding Machine Welders 8

Aluminum Types Of Mobile Welding Best Portable Welders Welding Machine For Sale 4





Frequently Asked Questions

1. When can you arrange shippment?
The shippment is 15 days after getting deopsit, but customized machines should be more than 25 days.

2.Do you inspect the finished products?
Yes, each step of production products will be came out inspection by QC department before shipping.

3.Are you factory?
Yes, we are factory, all machine is made by ourself and we can provide customize service according to your requirement.

4.How to buy your Spot Welder?
Please send us inquiry to our email, and we will give you a PI to send us payment.

5. How to contact you?
You can send a mail for us and call us.

6.How will you deliver my goods to me?
We always ship by air and sea in the mean time.

7.How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.

8.What kind of payment do you accept?
T/T, Western Union, PayPal, .L/C, D/A, etc.
