Portable Spot Welding Machine
Created with Pixso.

Hand Held 1300mm Portable Spot Welding Machine 360 Degree Rotating

Hand Held 1300mm Portable Spot Welding Machine 360 Degree Rotating

Brand Name: XWH
Model Number: DN2
MOQ: 1 Set
Price: $3,000.00-$5,000.00
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Set/Sets per Week
Detail Information
Place of Origin:
China
Certification:
CE
Product Name:
Portable Spot Welding Machine For Air Conditioner And Cabinet
Machine Type:
Auto Repair Tools
Rated Capacity:
Customized
After Warranty Service::
Video Technical Support, Online Support, Spare Parts, Field Maint
Weight (KG):
80 KG
Max. Welding Thickness:
3.5+3.5mm
Rated Duty Cycle:
50%
Voltage:
380V/220V
Packaging Details:
wooden Case
Supply Ability:
500 Set/Sets per Week
Highlight:

1300mm portable spot welding machine

,

360 degree rotating portable spot welding machine

,

1300mm hand held spot welder

Product Description
Portable Spot Welding Machine for Air Conditioner and Cabinet


MAIN FEATURES

1. Light weight, easy to operate and save electricity
2. Compact structure and easy maintenance
3. The turntable is equipped with bearings and rotates 360°
4. Customized welding tongs, the longest welding arm is 1300mm and the shortest is 220mm
5. Less wearing parts and high cost performance
6. The structure of the transformer is the same as that of Bosch. The transformer is equipped with temperature control protection. Water cooling, fast heat dissipation. Long sustainable working time (24h work)
7. Different specifications can be set (workpieces with different thicknesses can be welded) welding thickness 0.3mm+0.3mm∽5+5mm
8. Stable control functions
9. The cylinder is a customized pressurized cylinder, the brand is (SMC)
10. Balancer with self-locking function
11. The delivery period is stable and timely



Specifics

Most Popular 220V 380V Portable Suspended Spot Welding Gun
